Introduction #
Authors introduce the Trunk component for instance segmentation within The Tree Dataset of Urban Street, encompassing 7,675 high-resolution images distributed across 29 distinct classes (trunk_of_acer_palmatum, trunk_of_aesculus_chinensis etc.). This specific section is designed to facilitate the precise delineation and identification of individual tree instances within the urban landscape. With these comprehensive resources at your disposal, this subset empowers researchers and practitioners to delve deep into the detailed analysis of urban street greenery, offering a valuable resource for comprehensive instance segmentation studies. Automatic tree species identification can be used to realize autonomous street tree inventories and help people without botanical knowledge and experience to better understand the diversity and regionalization of different urban landscapes.
The Tree Dataset of Urban Street sub-datasets:
Classification:
- Branch 1485 images, 13 classes (1.4G) (available on DatasetNinja)
- Trunk 7675 images, 29 classes (6.4G) (current dataset includes classification tags)
- Leaf 21127 images, 50 classes (13.6G) (available on DatasetNinja)
- Tree 4804 images, 23 classes (4.3G) (available on DatasetNinja)
- Fruit 4101 images, 29 classes (2.1G) (available on DatasetNinja)
- Flower 2275 images, 17 classes (1.3G) (available on DatasetNinja)
Segmentation:
- Tree 3949 images, 22 classes (7.9G) (available on DatasetNinja)
- Branch 1485 images, 13 classes (3.1G) (available on DatasetNinja)
- Trunk 7675 images, 29 classes (12.9G) (current)
- Leaf 9763 images, 39 classes (10.2G) (available on DatasetNinja)
Detection:
- Leaf 9763 images, 39 classes (11G) (available on DatasetNinja)
Examples of Urban Street: Trunk (segmenation task).
Annotations were performed in a fine-grained manner by using polygons (bitmap in supervisely) to outline individual objects. Authors assessed the performance of various vision algorithms on different classification and segmentation tasks, including tree species identification and instance segmentation.
The proposed dataset was designed to capture urban street trees with subtropical or temperate monsoon climates in China. Our data collection and annotation methods were carefully created to capture the high variability of street trees. From February to October 2022, tens of thousands of tree images were acquired with mobile devices, covering spring, summer, fall and winter in 10 cities.
Similar to Cityscapes (Cordts et al., 2016) (available on DatasetNinja) and ADE20K (Zhou et al., 2019) (available on DatasetNinja), authors divide each organ dataset into separate training (train), validation (val) and test (test) sets.
Summary #
Tree Dataset of Urban Street: Trunk is a dataset for instance segmentation, semantic segmentation, object detection, and classification tasks. It is used in the environmental industry.
The dataset consists of 7675 images with 7766 labeled objects belonging to 29 different classes including trunk_of_styphnolobium_japonicum, trunk_of_koelreuteria_paniculata, trunk_of_magnolia_grandiflora_l., and other: trunk_of_michelia_chapensis, trunk_of_liquidambar_formosana, trunk_of_liriodendron_chinense, trunk_of_celtis_sinensis, trunk_of_zelkova_serrata, trunk_of_albizia_julibrissin, trunk_of_sapindus_saponaria, trunk_of_platanus, trunk_of_populus_l., trunk_of_flowering_cherry, trunk_of_salix_babylonica, trunk_of_camptotheca_acuminata, trunk_of_prunus_cerasifera_f._atropurpurea, trunk_of_osmanthus_fragrans, trunk_of_metasequoia_glyptostroboides, trunk_of_acer_palmatum, trunk_of_photinia_serratifolia, trunk_of_lagerstroemia_indica, trunk_of_ginkgo_biloba, trunk_of_aesculus_chinensis, trunk_of_triadica_sebifera, trunk_of_cinnamomum_camphora_(linn)_presl, trunk_of_elaeocarpus_decipiens, trunk_of_magnolia_liliflora_desr, trunk_of_cedrus_deodara, and trunk_of_malushalliana.
Images in the Urban Street: Trunk dataset have pixel-level instance segmentation annotations. Due to the nature of the instance segmentation task, it can be automatically transformed into a semantic segmentation (only one mask for every class) or object detection (bounding boxes for every object) tasks. All images are labeled (i.e. with annotations). There are 3 splits in the dataset: train (6150 images), val (767 images), and test (758 images). Also, the dataset includes classification_tag. The dataset was released in 2022 by the Zhejiang Agriculture and Forestry University.
Here is a visualized example for randomly selected sample classes:
Explore #
Urban Street: Trunk dataset has 7675 images. Click on one of the examples below or open "Explore" tool anytime you need to view dataset images with annotations. This tool has extended visualization capabilities like zoom, translation, objects table, custom filters and more. Hover the mouse over the images to hide or show annotations.
Class balance #
There are 29 annotation classes in the dataset. Find the general statistics and balances for every class in the table below. Click any row to preview images that have labels of the selected class. Sort by column to find the most rare or prevalent classes.
Class ã…¤ | Images ã…¤ | Objects ã…¤ | Count on image average | Area on image average |
---|---|---|---|---|
trunk_of_styphnolobium_japonicumâž” mask | 394 | 394 | 1 | 63.69% |
trunk_of_koelreuteria_paniculataâž” mask | 378 | 378 | 1 | 68.96% |
trunk_of_magnolia_grandiflora_l.âž” mask | 364 | 364 | 1 | 61.48% |
trunk_of_michelia_chapensisâž” mask | 352 | 352 | 1 | 65.03% |
trunk_of_liquidambar_formosanaâž” mask | 328 | 328 | 1 | 67.69% |
trunk_of_liriodendron_chinenseâž” mask | 321 | 321 | 1 | 63.3% |
trunk_of_celtis_sinensisâž” mask | 317 | 317 | 1 | 79.9% |
trunk_of_zelkova_serrataâž” mask | 312 | 313 | 1 | 55.21% |
trunk_of_albizia_julibrissinâž” mask | 311 | 312 | 1 | 61.28% |
trunk_of_sapindus_saponariaâž” mask | 295 | 296 | 1 | 63.54% |
Co-occurrence matrix #
Co-occurrence matrix is an extremely valuable tool that shows you the images for every pair of classes: how many images have objects of both classes at the same time. If you click any cell, you will see those images. We added the tooltip with an explanation for every cell for your convenience, just hover the mouse over a cell to preview the description.
Images #
Explore every single image in the dataset with respect to the number of annotations of each class it has. Click a row to preview selected image. Sort by any column to find anomalies and edge cases. Use horizontal scroll if the table has many columns for a large number of classes in the dataset.
Object distribution #
Interactive heatmap chart for every class with object distribution shows how many images are in the dataset with a certain number of objects of a specific class. Users can click cell and see the list of all corresponding images.
Class sizes #
The table below gives various size properties of objects for every class. Click a row to see the image with annotations of the selected class. Sort columns to find classes with the smallest or largest objects or understand the size differences between classes.
Class | Object count | Avg area | Max area | Min area | Min height | Min height | Max height | Max height | Avg height | Avg height | Min width | Min width | Max width | Max width |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
trunk_of_styphnolobium_japonicum mask | 394 | 63.69% | 100% | 22.16% | 4006px | 99.36% | 4032px | 100% | 4031px | 99.98% | 945px | 31.25% | 3024px | 100% |
trunk_of_koelreuteria_paniculata mask | 378 | 68.96% | 100% | 7.65% | 1806px | 53.17% | 4032px | 100% | 3946px | 98.94% | 534px | 17.66% | 3024px | 100% |
trunk_of_magnolia_grandiflora_l. mask | 364 | 61.48% | 100% | 7.6% | 2391px | 59.3% | 4032px | 100% | 4013px | 99.6% | 421px | 13.92% | 3024px | 100% |
trunk_of_michelia_chapensis mask | 352 | 65.03% | 100% | 23.13% | 2835px | 70.31% | 4032px | 100% | 4015px | 99.57% | 788px | 26.06% | 3024px | 100% |
trunk_of_liquidambar_formosana mask | 328 | 67.69% | 100% | 14.87% | 2888px | 71.63% | 4032px | 100% | 4027px | 99.87% | 642px | 21.23% | 3024px | 100% |
trunk_of_liriodendron_chinense mask | 321 | 63.3% | 100% | 4.13% | 2027px | 50.27% | 4032px | 100% | 3874px | 96.09% | 481px | 15.91% | 3024px | 100% |
trunk_of_celtis_sinensis mask | 317 | 79.9% | 100% | 30.29% | 2970px | 73.66% | 4032px | 100% | 4027px | 99.88% | 1257px | 41.57% | 3024px | 100% |
trunk_of_zelkova_serrata mask | 313 | 55.03% | 99.63% | 4.54% | 1407px | 34.9% | 4032px | 100% | 3966px | 98.35% | 514px | 17% | 3024px | 100% |
trunk_of_albizia_julibrissin mask | 312 | 61.09% | 100% | 0.85% | 840px | 20.83% | 4032px | 100% | 3963px | 98.28% | 191px | 6.32% | 3024px | 100% |
trunk_of_sapindus_saponaria mask | 296 | 63.33% | 100% | 4.42% | 868px | 34.18% | 4032px | 100% | 3982px | 99.02% | 384px | 12.7% | 3024px | 100% |
Spatial Heatmap #
The heatmaps below give the spatial distributions of all objects for every class. These visualizations provide insights into the most probable and rare object locations on the image. It helps analyze objects' placements in a dataset.
Objects #
Table contains all 7766 objects. Click a row to preview an image with annotations, and use search or pagination to navigate. Sort columns to find outliers in the dataset.
Object ID ã…¤ | Class ã…¤ | Image name click row to open | Image size height x width | Height ã…¤ | Height ã…¤ | Width ã…¤ | Width ã…¤ | Area ã…¤ |
---|---|---|---|---|---|---|---|---|
1âž” | trunk_of_ginkgo_biloba mask | Ginkgo biloba_trunk_1 (43).jpg | 4032 x 3024 | 4032px | 100% | 2768px | 91.53% | 86.38% |
2âž” | trunk_of_liriodendron_chinense mask | Liriodendron chinense_trunk_1 (214).jpg | 4032 x 3024 | 4032px | 100% | 2808px | 92.86% | 89.21% |
3âž” | trunk_of_aesculus_chinensis mask | Aesculus chinensis_trunk_1 (159).jpg | 4032 x 3024 | 4032px | 100% | 2618px | 86.57% | 75.52% |
4âž” | trunk_of_liquidambar_formosana mask | Liquidambar formosana_trunk_1 (86).jpg | 4032 x 3024 | 4032px | 100% | 2373px | 78.47% | 76.78% |
5âž” | trunk_of_liquidambar_formosana mask | Liquidambar formosana_trunk_1 (120).jpg | 4032 x 3024 | 4032px | 100% | 1657px | 54.79% | 47.05% |
6âž” | trunk_of_acer_palmatum mask | Acer palmatum_trunk_1 (16).jpg | 4032 x 3024 | 4029px | 99.93% | 2981px | 98.58% | 32.99% |
7âž” | trunk_of_celtis_sinensis mask | Celtis sinensis_trunk_1 (203).jpg | 4032 x 3024 | 4032px | 100% | 3024px | 100% | 99.83% |
8âž” | trunk_of_elaeocarpus_decipiens mask | Elaeocarpus decipiens_trunk_1 (101).jpg | 4032 x 3024 | 4032px | 100% | 1788px | 59.13% | 52.31% |
9âž” | trunk_of_salix_babylonica mask | Salix babylonica_trunk_1 (221).jpg | 4032 x 3024 | 4026px | 99.85% | 1733px | 57.31% | 47.24% |
10âž” | trunk_of_flowering_cherry mask | Flowering cherry_trunk_1 (181).jpg | 4032 x 3024 | 4031px | 99.98% | 2079px | 68.75% | 44.88% |
License #
Tree Dataset of Urban Street: Trunk is under GNU LGPL 3.0 license.
Citation #
If you make use of the Urban Street: Trunk data, please cite the following reference:
@dataset{Urban Street: Trunk,
author={Tingting Yang and Suyin Zhou and Zhijie Huang and Aijun Xu and Junhua Ye and Jianxin Yin},
title={Tree Dataset of Urban Street: Trunk},
year={2022},
url={https://ytt917251944.github.io/dataset_jekyll/}
}
If you are happy with Dataset Ninja and use provided visualizations and tools in your work, please cite us:
@misc{ visualization-tools-for-urban-street-trunk-dataset,
title = { Visualization Tools for Urban Street: Trunk Dataset },
type = { Computer Vision Tools },
author = { Dataset Ninja },
howpublished = { \url{ https://datasetninja.com/urban-street-trunk } },
url = { https://datasetninja.com/urban-street-trunk },
journal = { Dataset Ninja },
publisher = { Dataset Ninja },
year = { 2024 },
month = { nov },
note = { visited on 2024-11-21 },
}
Download #
Dataset Urban Street: Trunk can be downloaded in Supervisely format:
As an alternative, it can be downloaded with dataset-tools package:
pip install --upgrade dataset-tools
… using following python code:
import dataset_tools as dtools
dtools.download(dataset='Urban Street: Trunk', dst_dir='~/dataset-ninja/')
Make sure not to overlook the python code example available on the Supervisely Developer Portal. It will give you a clear idea of how to effortlessly work with the downloaded dataset.
The data in original format can be downloaded here.
